6 REMOTE INTERFACE
APS-1102A 6-21

[SOURce:]FUNCtion[:SHAPe][:IMMediate]
This sets the output waveform. The output waveform setting is SIN/SQU/ARB1 to ARB16.
When in AC-EXT/AC+DC-EXT mode, the output waveform cannot be set. ([3, “Invalid in this
mode”] error occurs.)
Syntax: [SOURce:]FUNCtion[:SHAPe][:IMMediate]
Parameters: SIN/SQU/ARB1 to ARB16
Command example: FUNC SIN
Query example: FUNC?
Response format:
Response example: SIN

[SOURce:]MODE
This sets the output mode. There are eight output modes, each of them is a combination of one
operation mode (AC or AC+DC) and one signal source mode, (INT, EXT, ADD, or SYNC).
Consequently, the output mode setting is AC-INT, AC-EXT, AC-ADD, AC-SYNC, AC+DC-INT,
AC+DC-EXT, AC+DC-ADD, or AC+DC-SYNC.
However, when output is on, the output mode cannot be changed. ([1, “Invalid with output on”]
error occurs.)
Syntax: [SOURce:]MODE
Parameters: AC-INT/AC-EXT/AC-ADD/AC-SYNC/ACDC-INT
ACDC-EXT/ACDC-ADD/ACDC-SYNC
Command example: MODE ACDC-INT
Query example: MODE?
Response format:
Response example: ACDC-INT
