9 SPECIFICATIONS

APS-1102A

9-11

9.6 Sequence Function

Output parameters can be changed abruptly or swept in sequence.

Signal source is INT only.

Sequence function settings are stored in memory with battery backup.

a) Number of sequences

1 sequence per operation mode (AC or AC+DC mode) and

output range (100 V or 200 V)

b) Number of steps

1 to 255 (within 1 sequence)

c) Step time

0.1 ms to 999.9999 s (resolution 0.1 ms)

d) Operations within step

Constant, keep, or linear sweep

e) Parameters

DC voltage, AC voltage, frequency, waveform, and

synchronous step output (2 bits)

f) Jump times

1 to 999 or infinite

g) Sequence control

Start:

Starts a sequence.

Stop:

Stops a sequence.

Hold:

Maintains current step output. Restarted when a sequence is

started.

Branch:

Branches to the specified step.
