APS-1102A User Manual
APS-1102A 4-58
4.9 Amplification of External Signal
The APS-1102A can be used as an amplifier to which a signal is input from the external signal input
terminals on the rear panel, by selecting the external signal source mode (AC-EXT or AC+DC-EXT).
Connect the external signal source to the external signal input/external sync signal input terminal (EXT
SIG IN/EXT SYNC IN) on the rear panel. For this connection, use a coaxial cable with a BNC connector.
The input impedance is 10 k

(unbalanced) and the input frequency ranges from DC to 550 Hz.
Output voltage = input voltage × external input gain
Table4-15. External Input Gain Setting Range
Setting Setting Range Resolution Initial Value
External input gain
100 V range 0.0 to 220.0 0.1 100.0
200 V range 0.0 to 440.0 0.1 200.0
For description of the External signal input/external sync signal input terminal specifications:
See
“3.3.5 External signal input/external sync signal input terminal”.
Be sure to read this section carefully before entering settings, so as to prevent problems in this
product or the load.
！ CAUTION
