APS-1102A User Manual

APS-1102A

3-4

3.1.3 Rear panel

External signal input/external sync signal input connector

3.3.5

External control I/O connector

3.3.4

Output terminals

3.3.1

LINE INPUT

2.3

USB connector

3.3.3

Exhaust vent

RS232 connector

3.3.2

Figure 3-3. APS-1102A Rear Panel
