APS-1102A User Manual
APS-1102A 3-6
Table3-2. Settings in Memory (2/3)
Function Setting Initial setting Reset
Current limiter
Peak current limiter
(positive) 100 V range +42.0 A

200 V range +21.0 A
Peak current limiter
(negative) 100 V range

42.0 A
200 V range

21.0 A
RMS current limiter
100 V range 10.5 A
200 V range 5.3 A
Setting range limit
Positive voltage
setting limit 100 V range +220.0 V

200 V range +440.0 V
Negative voltage
setting limit 100 V range

220.0 V
200 V range

440.0 V
Frequency upper limit setting limit 550.0 Hz
Frequency lower limit setting limit 1.0 Hz
External input gain
setting
External input gain
100 V range 100
200 V range 200
Select measurement
display
Measurement display RMS
Sequence output
Step time 0.1000 s
Step operation type Constant (CONST)
Step end phase enable/disable Disable (DISABLE)
Step end phase 0.0

Step termination End (STOP)
Jump steps 0
Jump count 1
Branch steps 0
Adjusting DC offset
AC mode
100 V range 0.0 mV

200 V range 0.0 mV
DC mode
100 V range 0.0 mV
200 V range 0.0 mV
System settings
Keylock OFF
Beep ON
LCD contrast 55
LCD display color White(WHITE)
Time unit s
Output on/off at power-on OFF
External control input enable/disable Disable(DISABLE)
