Configuration Registers 4-3
Register: 0x00
Vendor ID
Read Only
VID Vendor ID [15:0]
This field identifies the manufacturer of the device. The
Vendor ID is 0x1000.
Register: 0x02
Device ID
Read Only
DID Device ID [15:0]
This field identifies the particular device. The
LSI53C825A device ID is 0x0003. This value is the same
as in the LSI53C825, since the LSI53C825A is a drop in
replacement. The devices are uniquely identified in the
upper nibble of the
Revision ID register.
Register: 0x04
Command
Read/Write
The Command register provides coarse control over a device’s ability to
generate and respond to PCI cycles. When a zero is written to this
register, the LSI53C825A is logically disconnected from the PCI bus for
all accesses except configuration accesses.
In the LSI53C825A, bits 3 through 5 and bit 7 and 9 are not
implemented. Bits 10 through 15 are reserved.
15 0
VID
1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0
15 0
DID
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
15 9 8 7 6 5 4 3 2 1 0
R SE R EPER R WIE R EBM EMS EIS
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
