1 first dword – Avago Technologies LSI53C825AE User Manual
Page 225
Load and Store Instructions
5-41
5.8.1 First Dword
IT[2:0]
Instruction Type
[31:29]
These bits should be 0b111, indicating the Load and
Store instruction.
DSA
DSA Relative
28
When this bit is cleared, the value in the
is the actual 32-bit memory address
used to perform the Load and Store to/from. When this
bit is set, the chip determines the memory address to
perform the Load and Store to/from by adding the 24-bit
signed offset value in the
to the
R
Reserved
[27:26]
NF
No Flush (Store instruction only)
25
When this bit is set, the LSI53C825A performs a Store
without flushing the prefetch unit. When this bit is cleared,
the Store instruction automatically flushes the prefetch
unit. Use No Flush if the source and destination are not
within four instructions of the current Store instruction.
This bit has no effect on the Load instruction.
Note:
This bit has no effect unless the Prefetch Enable bit in the
register is set.
LS
Load and Store
24
When this bit is set, the instruction is a Load. When
cleared, it is a Store.
R
Reserved
[23]
RA[6:0]
Register Address
[22:16]
A[6:0] selects the register to Load and Store to/from
within the LSI53C825A.
Note:
It is not possible to Load the
register, although it is possible to store the SFBR
contents to another location.
R
Reserved
[15:3]
BC
Byte Count
[2:0]
This value is the number of bytes to Load and Store.
