LSI53C825A/825AE PCI to SCSI I/O Processor 3-1
Chapter 3
Signal Descriptions
This chapter presents the LSI53C825A pin configuration and signal
definitions using tables and illustrations.
Figure 3.1 through Figure 3.2
are the pin diagrams for all versions of the LSI53C825A and Figure 3.3
is the functional signal grouping. The pin definitions are presented in
Table 3.1 through Table 3.10 . The LSI53C825A is a pin-for-pin
replacement for the LSI53C825. This chapter is divided into the following
sections:
•
Section 3.1, “PCI Bus Interface Signals”
•
Section 3.2, “MAD Bus Programming”
