5-34 SCSI SCRIPTS Instruction Set
Jump/Call an Absolute Address
Start execution at the new absolute address.
Jump/Call a Relative Address
Start execution at the current address plus (or minus) the
relative offset.
The SCRIPTS program counter is a 32-bit value pointing
to the SCRIPTS currently under execution by the
LSI53C825A. The next address is formed by adding the
32-bit program counter to the 24-bit signed value of the
last 24 bits of the Jump or Call instruction. Because it is
signed (2’s complement), the jump can be forward or
backward.
A relative transfer can be to any address within a
16 Mbyte segment. The program counter is combined
with the 24-bit signed offset (using addition or
subtraction) to form the new execution address.
SCRIPTS programs may contain a mixture of direct
jumps and relative jumps to provide maximum versatility
when writing SCRIPTS. For example, major sections of
code can be accessed with far calls using the 32-bit
physical address, then local labels can be called using
relative transfers. If a SCRIPT is written using only
relative transfers it does not require any run time
alteration of physical addresses, and can be stored in and
executed from a PROM.
CT Carry Test 21
When this bit is set, decisions based on the ALU carry bit
can be made. True/False comparisons are legal, but Data
Compare and Phase Compare are illegal.
Command Condition Codes
Absolute Alternate Address
Command Condition Codes
Don’t Care Alternate Jump Offset
