4-46

Registers

initiator or target mode. These bits are set when the
corresponding signal is active. They are useful when
operating in the low level mode.

Register: 0x0F (0x8F)

SCSI Status Two (SSTAT2)
Read Only

ILF1

SIDL Most Significant Byte Full

7

This bit is set when the most significant byte in the

SCSI

Input Data Latch (SIDL)

contains data. Data is transferred

from the SCSI bus to the

SCSI Input Data Latch (SIDL)

register before being sent to the DMA FIFO and then to
the host bus. The

SCSI Input Data Latch (SIDL)

register

contains SCSI data received asynchronously.
Synchronous data received does not flow through this
register.

ORF1

SODR Most Significant Byte Full

6

This bit is set when the most significant byte in the SCSI
Output Data register (SODR, a hidden buffer register
which is not accessible) contains data. The SODR
register is used by the SCSI logic as a second storage
register when sending data synchronously. It is not
accessible to the user. This bit is used to determine how
many bytes reside in the chip when an error occurs.

OLF1

SODL Most Significant Byte Full

5

This bit is set when the most significant byte in the

SCSI

Output Data Latch (SODL)

contains data. The

SCSI Out-

put Data Latch (SODL)

register is the interface between

the DMA logic and the SCSI bus. In synchronous mode,
data is transferred from the host bus to the

SCSI Output

Data Latch (SODL)

register, and then to the SCSI Output

Data register (SODR, a hidden buffer register which is
not accessible) before being sent to the SCSI bus. In
asynchronous mode, data is transferred from the host
bus to the

SCSI Output Data Latch (SODL)

register, and

then to the SCSI bus. The SODR buffer register is not

7

6

5

4

3

2

1

0

ILF

ORF1

OLF1

FF4

SPL1

DIFF

LDSC

SDP1

0

0

0

0

0

0

0

0
