Page 123: Scsi destination id (sdid)
Operating Registers
4-35
Register: 0x06 (0x86)
SCSI Destination ID (SDID)
Read/Write
R
Reserved
[7:4]
ENC[3:0]
Encoded Destination SCSI ID
[3:0]
Writing these bits sets the SCSI ID of the intended
initiator or target during SCSI reselection or selection
phases, respectively. When executing SCRIPTS, the
SCRIPTS processor writes the destination SCSI ID to
this register. The SCSI ID is defined by the user in a
SCRIPTS Select or Reselect instruction. The value
written is the binary-encoded ID. The priority of the
16 possible IDs, in descending order, is:
Register: 0x07 (0x87)
General Purpose (GPREG)
Read/Write
R
Reserved
[7:5]
GPIO[4:0]
General Purpose I/O
[4:0]
These bits are programmed through the
register as inputs, outputs, or to
perform special functions. As an output, these pins can
be used to enable or disable external terminators. It is
also possible to program these signals as live inputs and
sense them through a SCRIPTS register to register Move
