Register: 0x39 (0xB9)
DMA Interrupt Enable (DIEN)
Read/Write
R
Reserved
7
MDPE
Master Data Parity Error
6
BF
Bus Fault
5
ABRT
Aborted
4
SSI
Single Step Interrupt
3
SIR
SCRIPTS Interrupt Instruction Received
2
R
Reserved
1
IID
Illegal Instruction Detected
0
This register contains the interrupt mask bits corresponding to the
interrupting conditions described in the
register. An
interrupt is masked by clearing the appropriate mask bit. Masking an
interrupt prevents IRQ from being asserted for the corresponding
interrupt, but the status bit is still set in the
register.
Masking an interrupt does not prevent setting the
DIP. All DMA interrupts are considered fatal, therefore SCRIPTS stops
running when this condition occurs, whether or not the interrupt is
masked. Setting a mask bit enables the assertion of IRQ for the
corresponding interrupt. (A masked nonfatal interrupt does not prevent
unmasked or fatal interrupts from getting through; interrupt stacking
begins when either the
SIP or DIP bit is set.)
The LSI53C825A IRQ/ output is latched; once asserted, it remains
asserted until the interrupt is cleared by reading the appropriate status
register. Masking an interrupt after the IRQ/ output is asserted does not
cause IRQ/ to be deasserted.
For more information on interrupts, see
