Residual data in SCSI FIFO – starting a transfer other
than synchronous data receive with data left in the
SCSI synchronous receive FIFO.
UDC
Unexpected Disconnect
2
This condition only occurs in the initiator mode. It
happens when the target to which the LSI53C825A is
connected disconnects from the SCSI bus unexpectedly.
See the SCSI Disconnect Unexpected bit in the
register for more information on
expected versus unexpected disconnects. Any discon-
nect in the low level mode causes this condition.
RST
SCSI Reset Condition
1
Indicates assertion of the SRST/ signal by the
LSI53C825A or any other SCSI device. This condition is
edge-triggered, so multiple interrupts cannot occur
because of a single SRST/ pulse.
PAR
SCSI Parity Error
0
Indicates detection by the LSI53C825A of a parity error
while receiving or sending SCSI data. See the Disable
Halt on Parity Error or SATN/ Condition bits in the
register for more information on
when this condition is actually raised.
Register: 0x41 (0xC1)
SCSI Interrupt Enable One (SIEN1)
Read/Write
This register contains the interrupt mask bits corresponding to the
interrupting conditions described in the
register. An interrupt is masked by clearing the appropriate mask
bit. For more information on interrupts refer to
7
3
2
1
0
R
STO
GEN
HTH
x
x
x
x
x
0
0
0
