6-38 Specifications
Figure 6.25 Read Cycle, Slow Memory (
≥
64 Kbytes)
t
14s
t
18
t
19
t
17
t
11
t
12
t
13
t
15s
t
16s
CLK
MAS2/
(Driven by LSI53C825A)
MAS0/
(Driven by LSI53C825A)
MCE/
(Driven by LSI53C825A)
MOE/
(Driven by LSI53C825A)
MWE/
(Driven by LSI53C825A)
MAD
(Address driven by LSI53C825A;
Data driven by Memory)
Higher
Address
Middle
Address
Lower
Address
Valid Read Data
MAS1/
(Driven by LSI53C825A)
