Operating Registers

4-85

HTHSF

Handshake-to-Handshake Timer Scale Factor

4

Setting this bit causes this timer to shift by a factor of 16.
Refer to the

SCSI Timer Zero (STIME0)

register

description for details.

GEN[3:0]

General Purpose Timer Period

[3:0]

These bits select the period of the general purpose timer.
The time measured is the time between enabling and
disabling of the timer. When this timing is exceeded, the
GEN bit in the

SCSI Interrupt Status One (SIST1)

register

is set. Refer to the table under

SCSI Timer Zero

(STIME0)

, bits [3:0], for the available time-out periods.

Note:

To reset a timer before it expires and obtain repeatable
delays, the time value must be written to zero first, and then
written back to the desired value. This is also required
when changing from one time value to another. See

Chapter 2, “Functional Description,”

for an explanation of

how interrupts are generated when the timers expire.

1101

409.6 ms

6.4 s

1110

819.2 ms

12.8 s

1111

1.6 s

25.6 s

1. These values are correct if the CCF bits in the

SCSI

Control Three (SCNTL3)

register are set according to the

valid combinations in the bit description.

2. 50 MHz clock is not supported for Ultra2 SCSI operation.

Table 4.8

Timeout Periods, 50 MHz Clock (Cont.)

HTH[7:4], SEL[3:0],

GEN[3:0]

1

Minimum Timeout

(50 MHz Clock)

2

GENSF = 0

GENSF = 1
