Operating Registers 4-89
Register: 0x4E (0xCE)
SCSI Test Two (STEST2)
Read/Write
SCE SCSI Control Enable 7
Setting this bit allows assertion of all SCSI control and
data lines through the
SCSI Output Control Latch (SOCL)
and SCSI Output Data Latch (SODL) registers regardless
of whether the LSI53C825A is configured as a target or
initiator.
Note: Do not set this bit during normal operation, since it could
cause contention on the SCSI bus. It is included for
diagnostic purposes only.
ROF Reset SCSI Offset 6
Setting this bit clears any outstanding synchronous
SREQ/SACK offset. If a SCSI gross error occurs, set this
bit. This bit automatically clears itself after resetting the
synchronous offset.
DIF SCSI Differential Mode 5
Setting this bit allows the LSI53C825A to interface
properly to external differential transceivers. Its only real
effect is to 3-state the SBSY/, SSEL/, and SRST/ pads so
that they can be used as pure inputs. Clearing this bit
enables SE mode operation. This bit should be set in the
initialization routine if the differential pair interface is
used.
SLB SCSI Loopback Mode 4
Setting this bit allows the LSI53C825A to perform SCSI
loopback diagnostics. That is, it enables the SCSI core to
simultaneously perform as both the initiator and the
target.
7 6 5 4 3 2 1 0
SCE ROF DIF SLB SZM AWS EXT LOW
0 0 0 0 0 0 0 0
