3-4 Signal Descriptions
There are four signal type definitions:
I Input, a standard input-only signal.
O Output, a standard output driver (typically a Totem Pole Output).
T/S 3-state, a bidirectional, 3-state input/output signal.
S/T/S Sustained 3-state, an active LOW 3-state signal owned and driven by
one and only one agent at a time.
Table 3.1 LSI53C825A, LSI53C825AJ, LSI53C825AE, and
LSI53C825AJE Power and Ground Pins
Symbol Pin No. Description
V
SS
4, 10, 14, 18, 23, 27,
31, 37, 42, 48, 69, 79,
123, 133, 152, 158 Ground to the PCI I/O pins
V
DD
8, 33, 45, 63, 74, 84,
118, 128, 138 , 155
Power supplies to the Standard I/O pins
V
DD-I
1
1. These pins can accept a VDD source of 3.3 or 5 Volts. All other VDD pins
must be supplied 5 Volts.
8, 21, 33, 45, 155 V
DD
pad for PCI I/O pins
V
SS
-S 88, 93, 99, 104, 109,
114 Ground to the SCSI bus I/O pins
V
SS
-C 55, 146 Ground to the internal logic core
V
DD
-C 51, 149 Power supplies to the internal logic core
