4-88 Registers
to request data transfers. If the LSI53C825A SCSI is
functioning as a target, then the initiator has sent the
offset number of acknowledges.
SOM SCSI Synchronous Offset Maximum 0
This bit indicates that the current synchronous SREQ/,
SACK/ offset is the maximum specified by bits [3:0] in the
SCSI Transfer (SXFER) register. This bit is not latched
and may change at any time. It is used in low level
synchronous SCSI operations. When this bit is set, the
LSI53C825A SCSI is functioning as a target, and is
waiting for the initiator to acknowledge the data transfers.
If the LSI53C825A SCSI is functioning as an initiator,
then the target has sent the offset number of requests.
Register: 0x4D (0xCD)
SCSI Test One (STEST1)
Read/Write
SCLK SCSI Clock 7
When set, this bit disables the external SCLK (SCSI
Clock) pin, and the chip uses the PCI clock as the
internal SCSI clock. If a transfer rate of 10 Mbytes/s (or
20 Mbytes/s on a wide SCSI bus) is desired on the SCSI
bus, this bit must be cleared and at least a 40 MHz
external SCLK must be provided.
SISO SCSI Isolation Mode 6
This bit allows the LSI53C825A to put the SCSI
bidirectional and input pins into a low power mode when
the SCSI bus is not in use. When this bit is set, the SCSI
bus inputs are logically isolated from the SCSI bus.
R Reserved [5:0]
7 6 5 0
SCLK SISO R
0 0 x x x x x x
