Table 6.26

SCSI-2 Fast Transfers (10.0 Mbytes/s (8-Bit Transfers) or 20.0 Mbytes/s
(16-Bit Transfers), 40 MHz Clock)

Symbol

Parameter

Min

Max

Unit

t

1

Send SREQ/ or SACK/ assertion pulse width

35

ns

t

2

Send SREQ/ or SACK/ deassertion pulse width

35

ns

t

1

Receive SREQ/ or SACK/ assertion pulse width

20

ns

t

2

Receive SREQ/ or SACK/ deassertion pulse width

20

ns

t

3

Send data setup to SREQ/ or SACK/ asserted

33

ns

t

4

Send data hold from SREQ/ or SACK/ asserted

45

ns

t

5

Receive data setup to SREQ/ or SACK/ asserted

0

ns

t

6

Receive data hold from SREQ/ or SACK/ asserted

10

ns

Table 6.27

SCSI-2 Fast Transfers 10.0 Mbytes (8-Bit Transfers) or 20.0 Mbytes/s
(16-Bit Transfers) 50 MHz Clock

Symbol

Parameter

Min

Max

Unit

t

1

Send SREQ/ or SACK/ assertion pulse width

35

ns

t

2

Send SREQ/ or SACK/ deassertion pulse width

35

ns

t

1

Receive SREQ/ or SACK/ assertion pulse width

20

ns

t

2

Receive SREQ/ or SACK/ deassertion pulse width

20

ns

t

3

Send data setup to SREQ/ or SACK/ asserted

33

ns

t

4

Send data hold from SREQ/ or SACK/ asserted

40

1

1. Analysis of system configuration is recommended due to reduced driver skew margin in differential

systems.

Notes: Transfer period bits (bits [7:5] in the

SCSI Transfer (SXFER)

register) are set to zero and the

Extra Clock Cycle of Data Setup bit (bit 7 in

SCSI Control One (SCNTL1)

) is set. For Fast SCSI,

set the TolerANT Enable bit (bit 7 in

SCSI Test Three (STEST3)

).

ns

t

5

Receive data setup to SREQ/ or SACK/ asserted

0

ns

t

6

Receive data hold from SREQ/ or SACK/ asserted

10

ns
