Delta Electronics Human Machine Interface DOP-A Series User Manual
Page 300
Appendix A Specifications and Installation|ScrEdit Software User Manual
Revision Apr. 30th, 2007, 2007PDD23000002
A-7
DOP-A80THTD1/DOP-AE80THTD Units:
mm
Number
Description
A
Power Input Terminal
B
Battery Cover
C
USB Host
D
USB Client
E
COM1(RS232)
F
COM2(RS2323/RS422/RS485)
G
Extension slot for SM Card
H
Extension slot (For AE)
B
F
D
H
A
C
E
G
