Chapter 5 Control Block and Status Block|ScrEdit Software User Manual

Revision Apr. 30th, 2007, 2007PDD23000002

5-9

5.2 Status

Block

For two-way communication and display screen between DOP series and all brands’ PLC, it needs to input

starting address of response register in status block. The status block in DOP series HMI is a continuous

data block, such as Dm=D10 (length is 8 WORDs = D10-D17). When the control block size is set to 0, the

control block function is disabled. If the control block function is disabled, the status block function is also

disabled. When the status block function is enabled, the external controller, i.e. PLC can know the status of

HMI by writing the setting in status block. But, please note that the address of control block and status block

cannot be the same.

The function and explanation of each WORD are listed below. (In the following table, we assume that the

user will use a Delta PLC, so the available starting addresses in control block are Dm ~ Dm+7 (D10 ~ D17).)

Word Number

Register

0

Status Register for General Control (GCSR)

Dm

(D10)

1

Status Register for Screen Number (SNSR)

Dm+1

(D11)

2

Status Register for Curve Control (CCSR)

Dm+2

(D12)

3

Status Register for Sampling History Buffer (HSSR)

Dm+3

(D13)

4

Status Register for Clearing History Buffer (HCSR)

Dm+4

(D14)

5

Recipe Status Register (RESR)

Dm+5

(D15)

6

Status Register for Recipe Number (RBSR)

Dm+6

(D16)

7

Status Register 2 for General Control (GCSR2)

Dm+7

(D17)

„

Status Register for General Control (GCSR)

Bit Number

Function

0

Screen Switch Status

1~2 Reserved

3

Clear Status of Alarm Buffer

4

Clear Status of Alarm Counter

5-7 Reserved

8

User Level (Bit0)

9

User Level (Bit1)

10

User Level (Bit2)

11~15 Reserved

„

Screen Switch Status

When the screen is switched, the Bit will be set to ON. After screen switch is completed, the Bit will be

OFF.

„

Clear Status of Alarm Buffer

When HMI clear the alarm buffer (clear status of alarm buffer function is enabled), the Bit will be set to

ON. After this function is completed, the Bit will be OFF.
