Chapter 3 Element Function|ScrEdit Software User Manual

3-72

Revision Apr. 30th, 2007, 2007PDD23000002

Property Description of Alarm Moving Sign Element

Time

Provide HH:MM:SS and HH:MM two kinds of display format.

Date

Provide MM/DD/YY, DD/MM/YY and DD.MM.YY three kinds of display
format.

Alarm Number If this option is selected, when the alarm occurs, the alarm number that

is designated in Alarm Setup dialog box will also be shown in front of
the alarm message. Please refer to the figures below:

Detail

Color

When Time and Date these two options are selected, the user can
designate the display color by using this option.
