Chapter 5 Control Block and Status Block|ScrEdit Software User Manual

Revision Apr. 30th, 2007, 2007PDD23000002

5-13

Bit Number

Function

8 Printer

status

flag

9

Printer form feed status flag

10~15 Reserved

„

Multi-language Status Value

The user can know the current multi-language shown on HMI from the multi-language status value.

„

Printer Status Flag

When this flag is triggered to ON, it indicates that the printer is printing current display or editing screen.

When this flag is set to OFF, the printer function is disabled.

„

Printer Form Feed Status Flag

When this flag is triggered to ON, it indicates that the printer is retracting the paper and aligning the

paper for the next run automatically. When this flag is set to OFF, the printing form feed function is

disabled.
