Chapter 2 Creating and Editing Screens|ScrEdit Software User Manual

Revision Apr. 30th, 2007, 2007PDD23000002

2-99

Other tab in Configuration option

Enable Edit Multi-
Language User Interface

Use this option can enable multi-language user interface.
The user can view multi-language display in property table
if this option is selected. The editing interface will be
shown as the figure below:

Multi Language Function Example

Example:

Create a Screen that has “English”, “Traditional Chinese” and “Simplified Chinese” three languages selection

for the user to switch. Also, teach the user how to set an “Increment” button to switch the language selection

within the screen.

1. Create a new project.

Select HMI model “DOP-A57CSTD 256 Colors”.

2. Create two button elements on the screen. “Set” and “Increment” these two button elements.
