background image

Appendix A Specifications and Installation|ScrEdit Software User Manual

A-2

Revision Apr. 30th, 2007, 2007PDD23000002

MODEL

AS38BSTD(-W)

A(E)57BSTD(-W)

A(E)57GSTD(-W)

A(E)57CSTD(-W)

Vibration

Resistance

IEC61131-2 compliant

When vibration is NOT continuous: 5Hz-9Hz 3.5mm, 9Hz-150Hz 1G

When vibration is continuous: 5Hz-9Hz 1.75mm, 9Hz-150Hz 0.5G

X, Y, Z directions for 10 times

Dimensions

(W) x (H) x (D) mm

140.8 x 104.8 x 44.8

184.1 x 144.1 x 47

Weight

Approx. 315g

Approx. 768g

Operation Voltage

DC +24V (-10% ~ +15%) (Please use isolated power supply)

(Note 3)

Backup Battery

3V lithium battery CR2032 x 1 / battery life: 5 years

Buzzer

85dB

NOTE

1) Only DOP-AE94BSTD this model is not UL recognized.
2) The maximum visual performance of the models with 256 colors LCD module is 256 colors. However, in

order to make the created elements to be displayed with more brilliant colors, the ScrEdit software
(Screen Editor, the program editor of Delta HMI product) only provides 144 colors for user settings.

3) Users please use isolated power supply except DOP-AE80THTD, DOP-AE94BSTD, DOP-AE10THTD

these models.

4) Users can download the Screen Editor, the program editor of Delta HMI product and the user manual via

the following link:

http://www.delta.com.tw/industrialautomation/

.
