Alarm Setup Dialog Box

The calculation method of the size of the alarm history file is as follows:

[

]

{

}

Bytes

d

Bytes

c

N

b

Bytes

a

Bytes

Size

File

Actual

)

(

4

)

(

)

(

2

)

(

6

=

+

×

+

a

Time and Date Data

b

Alarm Data

c

Sampling Points

d

Data File Symbol


Example:
If the Number of Records in History Buffer is set to 100, and the time and date is
recorded, the required capacity for saving alarm data is:
[(6 Bytes + 2 Bytes) × 100] + 4 Bytes= 804 Bytes
If the Number of Records in History Buffer is set to 100, and the time and date is not
recorded, the required capacity for saving alarm data is:
(2 Bytes × 100) + 4 Bytes = 204 Bytes


The calculation method of the size of the alarm frequency table is as follows:

Bytes

b

N

a

Bytes

Size

File

Actual

)

(

)

(

2

=

×

a

Alarm Frequency Data

b

Alarm Type


Example:
If there are five alarm types, the required capacity for saving alarm data is:
2 Bytes × 5 = 10 Bytes

Enable

It is used to enable the alarm moving sign.

Position

It is used to determine the display position of alarm moving sign. It can
be Top or Bottom.

Left

Alarm message will move from right to left (Move to left).

Right Alarm message will move from left to right (Move to right).

Up

Alarm message will move from bottom to top (Move to Up).

Direction

Down Alarm message will move from top to bottom (Move to Down).

Moving points

It is used to set the moving points every time for the alarm moving sign.
The unit is Pixel and the range is within 1 ~ 50 points.

Interval (ms)

It is used to set the interval time every time for the alarm moving sign.
The unit is ms and the range is within 50 ~ 3000 ms.

Alarm Moving
Sign

Background
Color

It is used to set the background color of the alarm moving sign.

„

History Setup

History Setup should be used with sampling elements. Please refer to Chapter 3 for more detailed
information.
