Revision Apr. 30th, 2007, 2007PDD23000002

A-1

Appendix A Specifications and Installation

A.1 Specifications

MODEL

AS38BSTD(-W)

A(E)57BSTD(-W)

A(E)57GSTD(-W)

A(E)57CSTD(-W)

Operation System

Windows Base Real Time OS

MCU

32-bit RISC Micro-controller / 206.4MHz

NOR Flash ROM

NOR Flash ROM 2

Mbytes (System:

1MB / User: 1MB)

NOR Flash ROM 4 Mbytes (System: 1MB / User: 3MB)

SDRAM

4 Mbytes

16Mbytes

Backup Memory

(Bytes)

128K

A

:256K

AE

:512K

A

:256K

AE

:512K

A

:256K

AE

:512K

SM Card

3

3

3

EXT.
Mem

ory

USB Flash

Drive

3

Extension Interface

3

(AE)

3

(AE)

3

(AE)

USB for Download

[USB Client]

1 Client Ver 1.1

USB for Data

Storage / Printer

[USB Host]

3

Display Type

3.8” STN LCD

(8 shades of blue)

5.7” STN LCD

(8 shades of blue)

5.7” FSTN LCD

(16 shades of gray)

5.7” STN LCD

(256 colors)

(Note 2)

Resolution

320 x 240 pixels

Back Light

LED Back Light

(about 10 thousand

hours at 25

o

C)

CCFL Back Light (about 50 thousand hours at 25

o

C)

LCD MODUL

E

Display Size

3.8 inches

(76.8 x 57.6mm)

5.7 inches (115.17 x 86.37mm)

Function Key

User defined key x 4

Perpetual Calendar

(RTC)

Built-in

Cooling Method

Natural air circulation

Safety Approval

(Waterproof for

front panel)

IP65 / NEMA4 / CE, UL

Operating Temp.

0°C to 50°C

Storage Temp.

-20°C to +60°C

Ambient Humidity

10% ~ 90% RH [0 ~ 40°C], 10% ~ 55% RH [41 ~ 50°C]
