Delta Electronics Human Machine Interface DOP-A Series User Manual
Page 299
Appendix A Specifications and Installation|ScrEdit Software User Manual
A-6
Revision Apr. 30th, 2007, 2007PDD23000002
DOP-A(E)57G (B)(C)STD(-W)
Units: mm
Number
Description
A
COM2(RS2323/RS422/RS485)
B
COM1(RS232)
C
USB Client
D
Power Input Terminal
E
Extension slot for SM Card
F
Extension slot (For AE)
A
B C
E
D
F
