background image

Chapter 4 Macro Function|ScrEdit Software User Manual

Revision Apr. 30th, 2007, 2007PDD23000002

4-19

„

COT

Cotangent Function Operation

Equation: V1 = COT(V2) (Signed DW)

Perform the cotangent function operation on V2, and store the remainder in V1.

Example:

$0 = COT(50)

The result is $0 = 0.839

„

SEC

Secant Function Operation

Equation: V1 = SEC(V2) (Signed DW)

Perform the secant function operation on V2, and store the remainder in V1.

Example:

$0 = SEC(50)

The result is $0 = 1.556

„

CSC

Cosecant Function Operation

Equation: V1 = CSC(V2) (Signed DW)

Perform the cosecant function operation on V2, and store the remainder in V1.

Example:

$0 = CSC(50)

The result is $0 = 1.305

„

Logical Operation

Six logical operations includes OR, AND, XOR, NOT, Shift-left and Shift-right. There are three operands

for each operation. Each operand can be internal memory or constant. But it shall be internal memory

only when outputting. The unit can be Word and Double Word. Please refer to following table 4.3.2 and

examples below for more information.

Command

Equation

Description

Remark

|

V1 = V2 | V3

Bit OR operation

&&

V1 = V2 && V3

Bit AND operation

^

V1 = V2 ^ V3

Bit XOR operation

NOT

V1 = NOT V2

Bit NOT operation

<<

V1 = V2 << V3

Bit Shift-left operation

>>

V1 = V2 >> V3

Bit Shift-rightt operation

The calculation result can be
stored as WORD and
DWORD.
V1 can be internal memory
only.
V2 and V3 can be internal
memory or constant.

Table 4.3.2 Logical operation command table
