Appendix A Specifications and Installation|ScrEdit Software User Manual

Revision Apr. 30th, 2007, 2007PDD23000002

A-3

MODEL

A80THTD1

AE80THTD

AE94BSTD

A10TCTD

AE10THTD

Operation System

Windows Base Real Time OS

MCU

32-bit RISC Micro-controller / 206.4MHz

NOR Flash ROM

NOR Flash ROM 8 Mbytes (System: 1MB / User: 7MB)

SDRAM

32 Mbytes

16Mbytes

32 Mbytes

Backup Memory

(Bytes)

512K

512K

512K

A

:256K

AE

:512K

SM Card

3

3

EXT.
Mem

ory

USB Disk

3

3

3

3

(AE)

Extension Interface

3

3

3

(AE)

USB for Download

[USB Client]

1 Client Ver 1.1

USB for Data

Storage / Printer

[USB Host]

3

3

3

3

(AE)

Display Type

8” TFT LCD

(65536 colors)

8” TFT LCD

(65536 colors)

9.4” STN LCD

(8 shades of blue)

10.4” TFT LCD

(A

:256 colors

AE

:65536 colors)

Resolution

640 x 480 pixels

Back Light

2CCFL Back Light

(about 50 thousand hours at 25

o

C)

CCFL Back Light

(about 30 thousand

hours at 25

o

C)

2CCFL Back Light

(about 30 thousand

hours at 25

o

C)

LCD MODUL

E

Display Size

8 inches

(162.2 x 121.7mm)

8 inches

(162.2 x 121.7mm)

9.4 inches

(192.0 x 144.0mm)

10.4 inches

(211.2 x 158.4mm)

Function Key

User defined key x 6

User defined key x

11

User defined key x 7

Perpetual Calendar

(RTC)

Built-in

Cooling Method

Natural air circulation

Safety Approval

(Waterproof for

front panel)

IP65 / NEMA4 / CE, UL

(Note 1)

Operating Temp.

0°C to 50°C

Storage Temp.

-20°C to +60°C

Ambient Humidity

10% ~ 90% RH [0 ~ 40°C], 10% ~ 55% RH [41 ~ 50°C]

Vibration

Resistance

IEC61131-2 compliant

When vibration is NOT continuous: 5Hz-9Hz 3.5mm, 9Hz-150Hz 1G

When vibration is continuous: 5Hz-9Hz 1.75mm, 9Hz-150Hz 0.5G

X, Y, Z directions for 10 times

Dimensions

(W) x (H) x (D) mm

243.1 x 178.1 x 52.4 243.1 x 178.1 x 52.4 297.1 x 222.1 x 50.9 297.1 x 222.1 x 51.1

Weight

Approx. 1147g

Approx. 1147g

Approx. 1930g

Approx. 1721g
