Chapter 2 Creating and Editing Screens|ScrEdit Software User Manual

2-112

Revision Apr. 30th, 2007, 2007PDD23000002

Print Typesetting Function

The user can print many pages one time and arrange the layout of the print screen by using print typesetting

function. The history data also can be printed at the same time. Please pay particular attention to the

following notes when using print typesetting function.

1. The screen cannot be designated to print typesetting screen when switching HMI screen.

2. Print typesetting screen cannot be the default HMI screen.

3. Print typesetting screen cannot be the base screen.

4. Print typesetting screen cannot be the screen saver.

5. Print typesetting screen cannot be the sub-screen.

Create Printing Report

Step 1:

Creating a new screen first (Click Screen > New Screen) and set it as Apply Print Screen in Screen

Properties tab (Click Screen > Screen Properties). For the description of Apply Print Screen function,

please refer to Table. 2.7.2 Screen Properties setting on page 2-59.

Step 2:

Create the element that the user wants to print out. For example, if the user wants to print a Historical Trend

Graph and a X-Y Chart, the user can create a Historical Trend Graph (Click Element > Sampling >

Historical Trend Graph) and a X-Y Chart (Click Element > Curve > X-Y Chart) first and then set their

properties in the Property table. The Property table provides element property setting for each element. For

the information for element property settings for each element, please refer to Chapter 3 for more detailed

description.
