Chapter 2 Creating and Editing Screens|ScrEdit Software User Manual

Revision Apr. 30th, 2007, 2007PDD23000002

2-93

Standard tab in Configuration option

Dynamic

When communicating with the controller, read the address
value and optimize the elements that show on the current
screen and adjust the read data length according to the
number of screen elements. It can save the communication
time between HMI and the controller efficiently. We
recommend the user to use this function if there is no special
requirement.
Please note that this Dynamic Optimize function is enabled by
the Optimize option in Communication tab. If the Optimize
option in Communication tab is not selected, even the user
chooses this function in Standard tab, system will not activate
the Dynamic Optimize function.

Optimize Type

Static

When communicating with the controller, read the address
value and optimize the elements that show on the current
screen but will not adjust the read data length according to
the number of screen elements.
Please note that this Static Optimize function is enabled by
the Optimize option in Communication tab. If the Optimize
option in Communication tab is not selected, even the user
chooses this function in Standard tab, system will not activate
the Static Optimize function.

Upload / Download

The user can select USB or PC communication port (i.e. RS-232) to upload and
download.

Startup Delay Time

It is used to set the delay time for the startup of the external controller (i.e.
PLC). PLC. The range is 0 ~ 255 seconds.

Clock Macro Delay

It is used to set interval time when executing clock macro every time. The range
is 100 ~ 65535ms.

Table 2.9.2 Communication Tab

Communication tab in Configuration option
