Chapter 4 Macro Function|ScrEdit Software User Manual

Revision Apr. 30th, 2007, 2007PDD23000002

4-23

FILL(V1, V2, V3) means to fill address V1 with data in address V2 and the data number is V3. If

the block length is more than internal memory or maximum number of PLC address, there will

be error occurred when compiling.

Example:

$5 = 10

FILL($0, $5, 4)

Executing FILL command to fill $0, $1, $2, $3 with constant 10.

„

CHR

Convert Text to ASCII code

Equation: CHR(V1, "V2")

CHR(V1, "V2") means to convert text in address V2 to ASCII code and store in V1. The maximum

length is 128 words. One address can store up to two words. The excess word will be stored in

next address in order. The low and high bit of the converted ASCII code will be exchanged.

Example:

CHR($1, "AB12")

After executing CHR command, 4241H will be stored in $1 and 3130H will be stored in $2.

„

FMOV

Transfer Floating Point Data

Equation: V1 = FMOV(V2) (Signed DW)

Transfer floating point data from V2 to V1. No data change within V2 after the command is

executed.

Example:

Transfer constant 44.3 to the internal memory address $0.

$0 = FMOV(44.3) (Signed DW)

Transfer the same data of PLC 1@C200 to the internal memory address $0.

$0 = FMOV(1@C200) (Signed DW)

„

Data Conversion

Command

Equation

Description

BCD

V1 = BCD(V2)

Converts BIN Data into BCD

BIN

V1 = BIN(V2)

Decimal value conversion

W2D

V1 = W2D(V2)

Convert WORD to DWORD

B2W

V1 = B2W(V2, V3)

Convert BYTE to WORD

W2B

V1 = W2B(V2, V3)

Convert WORD to BYTE

SWAP

SWAP (V1, V2, V3)

Swap BYTE data of the WORD

XCHG

XCHG (V1, V2, V3)

Exchange data
