Chapter 5 Control Block and Status Block|ScrEdit Software User Manual

Revision Apr. 30th, 2007, 2007PDD23000002

5-7

„

Control Flag for Writing Recipe

Before writing a recipe to PLC, the user should designate the recipe number (N) first (Please refer to

the section “

Control Flag for Changing Recipe Number

”). Then, trigger this control flag to ON (Bit 2 is

set to ON). After setting, the recipe will be written to PLC. This flag needs be set to OFF and then ON if

the user wants to trigger again.

„

Control Flag for Changing Recipe Group Number

There are two kinds of methods for changing and calling recipe group number. One method is to use

HMI internal register, RCPG directly. RCPG is the internal system register used for designating recipe

group number. The other method is to use

Recipe Control Register (RECR) (Dn+5). When the user

wants to change HMI recipe group number through control block settings, first, it needs to write recipe

group number (N) into the high byte of this control block and use this control flag to trigger, Dn+5 (Bit 3

is set to ON). After setting, RCPG will be changed to N automatically. This flag needs be set to OFF

and then ON if the user wants to trigger again.

„

Register for Designating Recipe Number (RBIR)

Word

Function

0

Designate receipt number which the user wants to change

By writing recipe group number (N) into Designated Recipe Number Register (RBIR), RCPNO value can be

changed. The user can use the control flag for changing recipe number of Recipe Control Register (RECR)

to write recipe group number (N) into Designated Recipe Number Register (RBIR) and change RCPNO

value.

„

System Control Flag Register (SCFR)

Bit Number

Function

0

Multi-language setting value Bit 0

1

Multi-language setting value Bit 1

2

Multi-language setting value Bit 2

3

Multi-language setting value Bit 3

4

Multi-language setting value Bit 4

5

Multi-language setting value Bit 5

6

Multi-language setting value Bit 6

7

Multi-language setting value Bit 7

8 Printer

flag

9

Printer form feed flag

10~15 Reserved

„

Multi-Language Setting Value

Store the designating multi-language setting value into this register and command HMI to switch to the
