Chapter 4 Macro Function|ScrEdit Software User Manual

Revision Apr. 30th, 2007, 2007PDD23000002

4-33

$2 = 1111111111111111B

CLRB $2.15

The result is $2 = 0111111111111111B

„

INVB

Set specific bit to be inversed. ON Æ OFF, OFF Æ ON

Equation: INVB V1

Set V1 Bit to be inversed. ON Æ OFF, OFF Æ ON

Example:

Set the value of 0th Bit within the internal memory $3 to be inversed.

$3 = 1111111111111111B

INVB $3.0

The result is $3 = 1111111111111110B

„

GETB

Get bit value

Equation: V1 = GETB V2

Get V2 Bit value and store in V1

Example:

Get the value of 3rd Bit within the internal memory $0 and store it to the 5th Bit within the internal

memory $10.

$0 = 0000000000000100B

$10 = 0

$10.5 = GETB $0.3

The result is $10 = 0000000000010000B

„

Communication

Command

Equation

Description

INITCOM

V1= INITCOM (V2)

Initial setup COM port

ADDSUM

V1=ADDSUM(V2, V3)

Use addition to calculate checksum

XORSUM

V1 = XORSUM(V2, V3)

Use XOR to calculate checksum

PUTCHARS

V1 = PUTCHARS(V2, V3, V4)

Output characters by COM port

GETCHARS

V1 = GETCHARS(V2, V3, V4)

Get characters by COM port

SELECTCOM

SELECTCOM(V1)

Select COM port

CLEARCOMBUFFER

CLEARCOMBUFFER(V1, V2)

Clear COM port buffer

CHRCHKSUM

V1 = CHRCHKSUM(V2, V3, V4)

Calculate the length of texts and
checksum

Table 4.3.7 Communication command table
