Chapter 5 Control Block and Status Block|ScrEdit Software User Manual

Revision Apr. 30th, 2007, 2007PDD23000002

5-11

„

Curve Sampling Status Flag

When sampling general trend graph or X-Y chart, the curve sampling status flag will be set to be ON

(Bit 0 ~ Bit 3 is set to ON). After sampling operation is completed, the curve sampling status flag will be

OFF.

„

Curve Clear Status Flag

When clearing general trend graph or X-Y chart, the curve clear status flag will be set to be ON (Bit 8 ~

Bit 11 is set to ON). After clear operation is completed, the curve clear status flag will be OFF.

„

Status Register for Sampling History Buffer (HSSR)

Bit Number

Function

0

Sampling Status of History Buffer 1

1

Sampling Status of History Buffer 2

2

Sampling Status of History Buffer 3

3

Sampling Status of History Buffer 4

4

Sampling Status of History Buffer 5

5

Sampling Status of History Buffer 6

6

Sampling Status of History Buffer 7

7

Sampling Status of History Buffer 8

8

Sampling Status of History Buffer 9

9

Sampling Status of History Buffer 10

10

Sampling Status of History Buffer 11

11

Sampling Status of History Buffer 12

12-15 Reserved

„

Sampling History Buffer Flag

When sampling history buffer, the sampling history buffer flag will be set to be ON (Bit 0 ~ Bit 11 is set

to ON). After sampling operation is completed, the sampling history buffer flag will be OFF.

„

Status Register for Clearing History Buffer (HCSR)

Bit Number

Function

0

Clear Status of History Buffer 1

1

Clear Status of History Buffer 2

2

Clear Status of History Buffer 3

3

Clear Status of History Buffer 4

4

Clear Status of History Buffer 5

5

Clear Status of History Buffer 6

6

Clear Status of History Buffer 7

7

Clear Status of History Buffer 8

8

Clear Status of History Buffer 9
