Parameter
Value
Description
Frame/Field 1: Ancillary packet
insertion line
32–65536, Default = 0 Specify the line where ancillary packet
insertion starts.
Frame/Field 1: Horizontal
blanking
32–65536, Default = 0 Specify the size of the horizontal blanking
period in pixels for Frame/Field 1.
Frame/Field 1: Vertical blanking 32–65536, Default = 0 Specify the size of the vertical blanking period
in pixels for Frame/Field 1.
Frame/Field 1: Horizontal sync
32–65536, Default = 60 Specify the size of the horizontal synchroni‐
zation period in pixels for Frame/Field 1.
Frame/Field 1: Horizontal front
porch
32–65536, Default = 20 Specify the size of the horizontal front porch
period in pixels for Frame/Field 1.
Frame/Field 1: Horizontal back
porch
32–65536, Default =
192
Specify the size of the horizontal back porch
in pixels for Frame/Field 1.
Frame/Field 1: Vertical sync
32–65536, Default = 5 Specify the number of lines in the vertical
synchronization period for Frame/Field 1.
Frame/Field 1: Vertical front
porch
32–65536, Default = 4 Specify the number of lines in the vertical
front porch period in pixels for Frame/Field
1.
Frame/Field 1: Vertical back
porch
32–65536, Default = 36 Specify the number of lines in the vertical
back porch in pixels for Frame/Field 1.
Interlaced and Field 0: F rising
edge line
32–65536, Default = 0 Specify the line when the rising edge of the
field bit occurs for Interlaced and Field 0.
Interlaced and Field 0: F falling
edge line
32–65536, Default = 18 Specify the line when the falling edge of the
field bit occurs for Interlaced and Field 0.
Interlaced and Field 0: Vertical
blanking rising edge line
32–65536, Default = 0 Specify the line when the rising edge of the
vertical blanking bit for Field 0 occurs for
Interlaced and Field 0.
Interlaced and Field 0: Ancillary
packet insertion line
32–65536, Default = 0 Specify the line where ancillary packet
insertion starts.
Interlaced and Field 0: Vertical
blanking
32–65536, Default = 0 Specify the size of the vertical blanking period
in pixels for Interlaced and Field 0.
Interlaced and Field 0: Vertical
sync
32–65536, Default = 0 Specify the number of lines in the vertical
synchronization period for Interlaced and
Field 0.
Interlaced and Field 0: Vertical
front porch
32–65536, Default = 0 Specify the number of lines in the vertical
front porch period for Interlaced and Field 0.
Interlaced and Field 0: Vertical
back porch
32–65536, Default = 0 Specify the number of lines in the vertical
back porch period for Interlaced and Field 0.
