Metrohm 797 VA Computrace - Manual (Page 82)

4 Exploratory mode
797 VA Computrace – Software
70
4 Exploratory mode
4.1 Exploratory mode overview
Exploratory mode features
The program part "Exploratory" has been especially designed for
practice-oriented qualitative voltammetric analysis. It com-
prises ten different measurement techniques and is curve oriented.
You are shown voltammograms and the associated parameters in
two windows next to each other. The various voltammograms can
be superimposed on one another thus making comparison of the
curves extremely simple.
Peaks or waves of the measured curves can be evaluated automati-
cally or manually after setting the base points. Tracing the curves
with a cursor allows the measured current and voltage values to be
accessed.
Thanks to its possibilities, this program part is helpful in the devel-
opment and optimization of methods for the quantitative determi-
nation of substances. The optimized voltammetric parameters can
be transferred directly to the working method in the program part
"Determination".
Exploratory mode selection
MAIN WINDOW / Mode / Exploratory
Switching to the exploratory mode for recording
and displaying of signals.
Exploratory mode windows
MAIN WINDOW / Window / Exploratory specification (F11)
The EXPLORATORY SPECIFICATION window will
be opened or (if it is already open) closed.
MAIN WINDOW / Window / Exploratory curves (F12)
The EXPLORATORY CURVES window will be
opened or (if it is already open) closed.
