2 Main window

797 VA Computrace – Software

Export previously saved determination data to the
database.

Procedure after starting

Export To Database / De-

termination Files..

The

Select Determination Files

window opens,

choose the determination(s) you want to export
and click .
If

Ask for database file..

is activated for

Manual

Transfer Mode

on the

Database

tab in the

GEN-

ERAL SETTINGS

window, the

SELECT DETERMI-

NATION DATABASE FILE

window opens, and you

choose the database file where the selected de-
termination(s) is(are) stored.
If

Use default database file..

is activated, the se-

lected determination(s) is(are) stored automatically
in the

Default database file

Note:

If you work with the new program version «797 VA

Computrace Software 1.3.x» and try to export to a data-
base created with an old program version «797 VA Com-
putrace Software 1.X», an error message appears (see
Error message "Please select a new database file"). If you
work with the «797 VA Computrace Software 1.3.x», ex-
port only to databases created with «797 VA Computrace
Software 1.3.x».

MAIN WINDOW

/ File / Import from Database..

Import a determination from the database.

Note:

Before importing: In your Autodatabase

software, open database file from which you want
to export a determination. Open next a report
template in the report window of your Autodata-
base software. Select then the determination in
the

EXPLORER

window first, before clicking on the

REPORT

window to activate it (highlighted).

Signal files

Signal files (

*.sig

) contain the measurement data and specifications

of a signal recorded in the exploratory mode. They can only be
loaded or saved in this mode.

MAIN WINDOW

/ File / New parameters

Load default parameters for selected electrode
and measurement mode.

MAIN WINDOW

/ File / Load signal

Load an existing signal file. Normally, signal files
are stored in the

Data

folder.
