5 Determination mode
797 VA Computrace – Software
118
ERTIES window (details see Axis properties, sec-
tion 3.5).
MONITORING / Curve properties
The properties of the live curve can be set with the
Monitor curve tab of the GRAPHICAL PROPERTIES
window (details see Curve properties, section 3.5).
Copy to clipboard
MONITORING / Copy to clipboard
Copy the current live curve in the MONITORING
window to the clipboard.
5.4 Determination curves
Load/save determinations
Determination files ( *.dth ) contain the measurement data and the
determination method used. Existing files can be loaded, saved
again and exported by the following commands:
MAIN WINDOW / File / Load determination
Load an existing determination file into the work-
ing memory. The name of the determination
loaded is displayed in the status bar of the
MAIN
WINDOW .
The current working method is not automatically
overwritten by the determination method, but its
parameters can be copied to the working method
afterwards.
MAIN WINDOW / File / Save determination
Save the current determination loaded in the
working memory. The old file will be overwritten.
MAIN WINDOW / File / Save determination as ...
Save the current determination loaded in the
working memory in a new file. Enter name and di-
rectory for storage of the determination file. If the
file name already exists, windows asks if you want
to overwrite the existing file.
MAIN WINDOW / File / Save calibration curve
(only accessible, if “Record calibration curve” is
chosen for
Calibration on the WORKING METHOD
SPECIFICATION window)
Save the current calibration curve loaded in the
working memory. The old file will be overwritten.
MAIN WINDOW / File / Save calibration curve as
(only accessible, if “Record calibration curve” is
chosen for
Calibration on the WORKING METHOD
SPECIFICATION window)
