2.4 Mode menu
797 VA Computrace – Software
15
MAIN WINDOW / File / Save signal as ...
Save the current signal loaded in the working
memory in a new file. Enter name and directory
for storage of the signal file.
MAIN WINDOW / File / Export signal points
Save the measurement points of the sweep of the
current signal loaded in the working memory into
a data file (extension
*.txt ). This data file contains
a block of the used method parameters followed
by the sweep block of X and Y values preceded by
the number of measurement points. The data files
can be imported into spreadsheet programs like
Microsoft Excel.
Printing of reports and curves
MAIN WINDOW / File / Print (Ctrl+P)
Print reports and/or curves. Depending on the
mode selection, a window appears for selection of
the items to be printed (see section 4.4 Printing in
exploratory mode for exploratory mode, and sec-
tion 5.7 Printing in determination mode for de-
termination mode).
MAIN WINDOW / File / Printer setup
Selection of a printer and definition of paper size
and format.
MAIN WINDOW / File / Print GLP report
Print a GLP report created with the GLP Wizard.
Program exit
MAIN WINDOW / File / Exit
Quit the VA Computrace program.
The program is also quit by clicking on in the
upper right part of the MAIN WINDOW .
2.4 Mode menu
Exploratory mode selection
MAIN WINDOW / Mode / Exploratory
Switching to the exploratory mode for recording
and displaying of signals (see section 4).
Determination mode selection
MAIN WINDOW / Mode / Determination
Switching to the determination mode for recor-
