Preface
Advanced Programming Software User Manual
6–6
Note From the monitor file display, you can quickly access another file number
and/or rung within the program file by typing one of the following formats at the
command line:
•
file#,rung#
•
file#:rung#
•
file#;rung#
The display area shows the end rung. No other rungs exist. The data entry line
indicates the file number (2) and the cursored rung number (0). When you are
monitoring or editing a ladder program
no forces , forces DISABLED , or
forces ENABLED appear on the status line.
2. To insert a rung press
CONFIG OFFLINE
CONFIG
EDIT
F10
. The following rung functions appear:
F6
Press a key for desired editing function
(file 2, rung 0)
offline
no forces EDITS: NONE FILE EXAMPLE
DELETE
RUNG
F7
UNDEL
RUNG
F5
MODIFY
RUNG
F8
ADVANCD
EDITING
F4
INSERT
RUNG
F3
APPEND
RUNG
F9
TEST
EDITS
F2
ONLINE
CONFIG
F1
SAVE/GO
ONLINE
F10
CANCEL
EDITS
Function key [F10] only appears if you are using an SLC 5/03 or SLC 5/04
processor.
3. Press
CONFIG OFFLINE
CONFIG
INSERT
RUNG
F4
and the following menu appears:
Type a mnemonic or press a key for desired editing function
(file 2, rung 0)
offline
no forces RUNG INSERT File EXAMPLE
F1
BRANCH
F4
INSERT
INSTR
END
F10
ACCEPT
RUNG
F3
APPEND
INSTR
F6 F7
DELETE
INSTR
UNDEL
INSTR
F5
MODIFY
INSTR
