Preface
Advanced Programming Software User Manual
3–10
Configuring Your System Startup State
This function allows you to select the display that appears at system startup.
1.
At the main menu display press
CONFIG
OFFLINE
CONFIG
SYSTEM
CONFIGR
F6
. The following display appears:
F1
Editor Highlighting Style:
REVERSE
F3
Color Selection:
COLOR
F4
Bit Address Display:
F5
Printer Configuration
F6
System Startup State:
MAIN MENU
F7
Define Directory Paths
F8
Monitor M0/M1 Addresses:
DISABLED
F9 Save Configuration
F1
F6
F7
F3
F5
F9
EDITOR
HILIGHT
SYSTEM
STARTUP
DEFINE
DIR
COLOR
SELECT
PRINTER
CONFIG
SAVE
CONFIGR
Press a function key
SYSTEM CONFIGURATION
ESC exits/Alt–U aborts changes
F8
M0/M1
MONITOR
F4
BIT
DISPLAY
Function key [F6], System Startup scrolls through the following selections:
•
Main Menu
•
WHO Menu
•
Online Menu
•
Offline Menu
•
Offline Config Menu
•
Multi-point Menu (Available for SLC 5/03 OS302 and SLC 5/04 OS401
processors only.)
2.
Save the new configuration for future sessions by pressing
CONFIG
OFFLINE
CONFIG
SAVE
CONFIGR
F9
. The
message:
NEW CONFIGURATION SAVED TO FILE
is displayed.
