Navigating Through the Software
2–7
Offline Monitor File Display
The following display appears when you press
CONFIG OFFLINE
CONFIG
MONITOR
FILE
F8
from the previous menu.
Press a function key
(file 2, rung 0)
offline
no forces EDITS: NONE File 05TEST
F9
FORCE
F2
CONFIG
DISPLAY
] [
I:0.0
0
( )
O:0.0
0
(EN)
(DN)
TON
TIMER ON DELAY
Timer
EIGHT_SEC
Time Base 0.01
Preset 800
Accum 0
END
F10
EDIT
] [
T4:0
DN
OUT
IN
EIGHT
F3
EXIT
F6 F7 F8
SEARCH GENERAL
UTILITY
DATA
MONITOR
F5
DOCUMNT
F4
MULTI
POINT
This function key: Allows you to:
[F2] Configure Display
configure the ladder file display (display/suppress comments
and symbols).
[F4] MultiĆPoint
access the multiĆpoint list menu. (Available only for the
SLC 5/03 OS302 and SLC 5/04 OS401 processors and the
MicroLogix 1000 controllers.)
[F5] Document
document ladder files (add/delete/edit comments and
symbols).
[F6] Search search, search and replace instructions/addresses.
[F7] General Utility
monitor/edit the status data file. Also allows you to clear minor
and major faults and clear the workspace memory.
[F8] Data Monitor
monitor data file information and change the radix. You can
also edit data and move to the Force Monitor function.
[F9] Force
force I/O from the force table. You can also access the Data
Monitor display and monitor forced I/O.
[F10] Edit
edit rungs and instructions, cut/copy/paste (advanced editing),
test edits, and use the quick edit feature.
