Preface
Advanced Programming Software User Manual
12–4
Function Key Description
[F1] Online
Allows you to go online and communicate with the device at
the node address the cursor is highlighting.
[F2] Station Diagnostics
Allows you to monitor the diagnostics of the network and the
highlighted cursored node.
[F3] Set Owner
Allows your APS terminal to establish ownership of a
processor on the network. While your terminal is active on the
network, other programmers cannot access the processor.
[F4] Clear Ownership
Allows your APS terminal to clear the ownership it has
established with a processor, thus allowing other programmers
to access the processor.
[F7] Maximum Address
Allows you to set the maximum node address of any active
processor on the network. The valid range is 1Ć31. The
default selection is 1.
[F8] Node Address
Allows you to set or change the node address of any active
processor on the network. You must cycle power to the
processor for your changes to take effect.
[F9] Node Baud
Allows you to set or change the communication rate of any
active processor on the network. You must cycle power to the
processor for your changes to take effect.
Setting the Processor Node Address
1. Begin at the main menu and press
CONFIG OFFLINE
CONFIG
WHO
F5
, then
CONFIG OFFLINE
CONFIG
WHO
ACTIVE
F5
. The following
display appears:
0 TERM (31) 12 24
1 13 25
2 14 26
3 500-20 (31) 15 27
4 16 28
5 17 29
6 18 30
7 19 31
8 20
9 21
10 22
11 23
F2
STATION
DIAGS
Press a key for desired network function
WHO ACTIVE - Active Station Identification
ESC exits
F1
ONLINE
F3
SET
OWNER
F4
CLEAR
OWNER
F7
MAX
ADDRESS
F8
NODE
ADDRESS
F9
NODE
BAUD
