Preface
Advanced Programming Software User Manual
11–30
Function Key Description
[F8] Board Address
1784ĆKT
Allows you to enter the 1784ĆKTs board dip switch setting in a binary
format. Valid range is 000000–111111. The default is 000011.
1784ĆKT2
Allows you to select the four digit hexadecimal number that represents
the board segment address. Valid values are C000, C400, C800, CC00,
D000, D400, D800, and DC00. The default is C800.
[F9] Save to File Saves the selected parameters to the user file.
Interchange DH+ Direct
The Interchange DH
+
configuration is only available when using an SLC 5/04
processor with an interface card. The Current Device field displays the interface
card installed in your personal computer.
The following interface cards are available for configuration via the initialization
file (cfg_kt.ini):
•
1784-KT
•
1784-KL
•
1784-KT2
•
1784-KTX
•
1784-PCMK with a 1785-PCM4 cable
Note You must edit the initialization file (cfg_kt.ini) found in the INTERCHANGE
directory in order to use the Interchange DH
+
option. To do this, use the
INTERCHANGE Device Configuration utility that was loaded during the APS
installation procedure. Refer to chapter 1 in this manual for configuration
information.
If the INTERCHANGE driver is not loaded or the INTERCHANGE port selected is
not configured for use, all entries in the online configuration screen will display
asterisks (*), except SLC node addresses and the current INTERCHANGE port.
Refer to the Instruction Set Reference Manual for more information on the Data
Highway Plus communication protocol.
