Preface, Offline config – Rockwell Automation 9323-PA1E USER MANUAL APS 6.0 User Manual
Page 130
Preface
Advanced Programming Software User Manual
7–14
4.
The symbol
IN
appears above the instruction. Note that symbols are always
displayed in capital letters. You are now prompted for a symbol relating to
T4:0
. Type:
eight sec
and press
CONFIG
OFFLINE
CONFIG
NEXT
INSTR
F9
.
] [
Enter symbol
Relate T4:0/DN to
offline
no forces
File EXAMPLE2
F9
NEXT
INSTR
( )
(EN)
(DN)
TON
TIMER ON DELAY
Timer
EIGHT_SEC
Time Base
0.01
Preset
800
Accum
0
END
F10
PREV
INSTR
] [
T4:0
DN
EIGHT_SEC/DN
IN
1
O:2
1
I:1
5.
EIGHT_SEC
appears within the TON instruction and also above the XIC
instruction associated with the timer instruction. Note that the Done bit in rung
1 was automatically assigned the symbol
EIGHT_SEC/DN
. If you choose, you
can assign a different symbol for the Done bit. For example, type:
eight
and
press
CONFIG
OFFLINE
CONFIG
NEXT
INSTR
F9
. The following display appears.
