Configuring Your Programming Device for Online Communication
11–13
1770-KF3 or 1747-KE (Full-Duplex) Device Configuration
The 1770-KF3 or 1747-KE device establishes DF1 full-duplex communication with
or without a modem between the APS terminal and a device. Refer to the user
manuals for cabling guidelines used to establish communication for a modem or a
direct connection.
F1 Port COM1
Current Device KF3/KE (Full-Duplex)
F4 KF3/KE Address 0
F5 PROC Address 1
F6 MAX Node Address 31
F7 KF3/KE/Modem/Full-Duplex Configuration
F9 Save to File
F9
Press a function key
SAVE TO
FILE
F5 F6
PROC
ADDRESS
MAX
ADDRESS
F1
PORT
F2
SELECT
DEVICE
F4
KF3/KE
ADDRESS
ESC exits/Alt-U aborts changes
ONLINE CONFIGURATION
F7
DEVICE
CONFIG
Function Key Description
[F1] Port
Toggles between COM1 and COM2. This field determines
where the KF3/KE is connected to your computer.
[F2] Select Device
Toggles between the selected interface card and the interface
card selection menu.
[F4] KF3/KE Address
This is the node address of the KF3/KE on the DHĆ485
network.
[F5] Processor Address
This is the address of the processor the APS terminal attempts
to go online with through the KF3/KE. The default is 1.
[F6] Maximum Address
This is the maximum node address of the KF3/KE on the
DHĆ485 network. Valid range is 0–31 decimal. The default is
31.
[F7] Device Configuration
Allows you to select the configuration parameters for the
specified device.
[F9] Save to File
Allows you to save the established parameters to a user
configuration file that APS accesses to automatically set up
these parameters the next time you use the software.
