Creating and Configuring Processor Files
5–3
3. Press [ENTER] . This places the processor file name in the lower window.
4. The Create Processor File window lists the default processor, Bul. 1761. For
our example we are using the 1747-L532 processor. Cursor down to highlight
it. (If you are using a different processor, use the cursor keys to locate the
appropriate processor in the upper option window.) Press
CONFIG OFFLINE
CONFIG
SELECT
PROC
F2
.
If you select either an SLC 5/03 or SLC 5/04 processor, a display like the
following appears:
PROCESSOR INPUTS OUTPUTS
OPERATING SYSTEM
Press a Function key, ENTER to Select Processor, ESC to exit, or Alt–U to abort
F2
PAGE
DOWN
F1
PAGE
UP
NAME: EXAMPLE
F2 Processor: 1747-L532 5/03 CPU –12K USER MEMORY
CREATE PROCESSOR FILE
ESC exits/Alt–U aborts changes
1747-OS300 SERIES A
1747-OS301 SERIES A
1747-OS302 SERIES A
Check the label on your processor to verify which operating system you are
using. Highlight the correct operating system and press
[ENTER] . Note that
the status line does not reflect the current operating system.
Note If you are using a MicroLogix 1000 controller, press
CONFIG OFFLINE
CONFIG
SAVE &
EXIT
F8
and then move on to
step 10 on page 5–7.
