Preface
Advanced Programming Software User Manual
5–4
5. Press
CONFIG OFFLINE
CONFIG
CONFIGR
I/O
F5
. The following display appears:
RACK 1 = 1746-A4 4-SLOT Backplane
RACK 2 = NOT INSTALLED
RACK 3 = NOT INSTALLED
SLOT CATALOG # CARD DESCRIPTION
*0 1747-L532 5/03 CPU -12K USER MEMORY
*1
*2
*3
4
5
6
7
8
Press a function key
I/O CONFIGURATION FOR:EXAMPLE
F6 F7 F4 F5
DELETE
SLOT
UNDEL
SLOT
MODIFY
RACKS
MODIFY
SLOT
F8
EXIT
ESC exits
F9
SPIO
CONFIG
F1 F2
READ
CONFIG
ONLINE
CONFIG
The display title is I/O CONFIGURATION FOR:EXAMPLE . The chassis
selection is Rack 1 = 1746-A4, 4-slot. Racks 2 and 3 are not installed.
Slot 0 lists the processor, 1747-L532. Slots 1, 2, and 3 must be specified. (An
asterisk indicates the slot is available.)
SLC 5/03 and SLC 5/04 Processors – Reading I/O Configuration
The read I/O configuration function allows the programming device to read the
actual processor I/O configuration. Use function keys [F1], Read Configuration
and [F2], Online Configuration to perform this function.
When you press [F1], Read Configuration, APS attempts to attach to the
processor node specified in the current online configuration. If the attempt to
attach to the processor node fails, the message:
MESSAGE TIMEOUT–LOSS
OF COMMUNICATIONS is displayed.
If the current processor type is not an SLC 5/03 or SLC 5/04, as specified in the
online configuration, the message:
SELECTED PROCESSOR DOES NOT
SUPPORT THIS FEATURE, CHECK ONLINE CONFIGURATION is
displayed. To check the online configuration, press [F2], Online Configuration.
If necessary, change the processor node address and press [F9], Save To File.
